# -*- coding: utf-8 -*-
#author:day169
import
math
import
tkinter as
tk
from
PIL import Image
import
PIL.ImageGrab
from
ctypes import windll
root=tk.Tk()
root.title('My
Window')
root.geometry('1000x1000')
canvas=
tk.Canvas(root,width=800,height=800,bg='white')
canvas.place(x=100,y=100)
#canvas.pack()
global
glxystr
glxystr="'x=
0 ', y= '0'"
lblxy =
tk.Label( root,text=glxystr,bg='white')
lblxy.place(x=10,y=10,width=160)
class
Ptxy: # class Ptxy() is same as
class Ptxy
def __init__(self,x,y)
:
self.x=x
self.y=y
#return self.x, self.y --->do'nt
work不能直接呼叫
return self.x, self.y
def Ptxy(self):
#note here we can use ptxy or
Ptxy,PTXY,pTxy,此處可用與class
Ptxy相同名稱也可以用
ptxy ,PTXY,PTxy同價
return
self.x,self.y
#return self.x, self.y work
def
get_pixel(pti): #coordinate pti
is canvas relative to root widget
dc =
windll.user32.GetDC(0)
xroot=pti.x
yroot=pti.y
#rgb =
windll.gdi32.GetPixel(dc,event.x_root,event.y_root)
rgb =
windll.gdi32.GetPixel(dc,xroot,yroot)
r = rgb
& 0xff
g = (rgb
>> 8) & 0xff
b = (rgb
>> 16) & 0xff
print (r,g,b)
return r,g,b
def
ptMoveto(ptOrg,xmove,ymove):
xmoveto=ptOrg.x+xmove
ymoveto=ptOrg.y+ymove
ptmove=Ptxy(xmoveto,ymoveto)
return ptmove
def
ptCopyto(ptorg,xmove,ymove):
xmoveto=ptorg.x+xmove
ymoveto=ptorg.y+ymove
ptcopyto=Ptxy(xmoveto,ymoveto)
return ptorg,ptcopyto
#--------------------------------
def
get_pixel_colorw(i_x, i_y):# i_x,
i_y are absolute coordinateare of widget canvas絕對座標
import
win32gui
i_desktop_window_id = win32gui.GetDesktopWindow()
i_desktop_window_dc = win32gui.GetWindowDC(i_desktop_window_id)
long_colour = win32gui.GetPixel(i_desktop_window_dc, i_x, i_y)
i_colour = int(long_colour)
return (i_colour &
0xff), ((i_colour >>
8) &
0xff), ((i_colour >> 16)
& 0xff)
def
get_pixel_color(i_x, i_y):# i_x,
i_y are absolute coordinateare of widget canvas絕對座標
import
PIL.ImageGrab
print('get
color',PIL.ImageGrab.grab().load()[i_x, i_y])
return
PIL.ImageGrab.grab().load()[i_x, i_y]
print(get_pixel_color(0,0))
def
get_pixel_colour(pti):#ptiis
point absolute coordinateare of widget canvas絕對座標
#import PIL.ImageGrab
print('int(pti.x),int(pti.y)',int(pti.x),int(pti.y))
color=PIL.ImageGrab.grab().load()[int(pti.x),int(pti.y)]
print('int(pti.x),int(pti.y)',int(pti.x),int(pti.y),color)
return color
# return rgb(r,g,b)
def
get_pixel_colourA(i_x, i_y):#i_x,
i_y are absolute coordinateare of widget canvas絕對座標
#import PIL.ImageGrab
color=PIL.ImageGrab.grab().load()[i_x, i_y]
return color
# return rgb(r,g,b)
#print (get_pixel_colour(0, 0))
def
set_pixel_color(pti,rgbIn):
rgbuse=from_rgb(rgbIn)
print("rgb",rgbIn,rgbuse)
id=canvas.create_line(pti.x,pti.y,pti.x+1,pti.y,fill=rgbuse)
stri=canvas.coords(id)
print("id,stri",id,stri)
print('strii[0]',stri[0])
color=PIL.ImageGrab.grab().load()[int(stri[0]),int(stri[1])]
print('color
in set_pixel,stri[0],stri[1]',int(stri[0]),int(stri[1]),color)
return
id
class
line():
def __init__(self,pt0,pt1)
:
self.pt0=pt0
self.pt1=pt1
def line(self):
#callabl for both in main() and
other function建議使用
return
self.pt0,self.pt1
def
linelen(Linet):
ldist=math.sqrt((Linet.pt1.x-Linet.pt0.x)**2+(Linet.pt1.y-Linet.pt0.y)**2)
return ldist
def
ptptDist(pt0,pt1): # can be
called both by main() and other function,ptptDist可以在主程式及其他函數使
x0=pt0.x
y0=pt0.y
x1=pt1.x
y1=pt1.y
ldist=math.sqrt((x1-x0)**2+(y1-y0)**2)
return ldist
def
ptptLen(pt0,pt1):# callabe in
main() only,只能在主程式使用
try:
ldist=math.sqrt((pt1.x-pt0.x)**2+(pt1.y-pt0.y)**2)
print ('ldist=',ldist)
except:
x0=pt0.x
y0=pt0.y
x1=pt1.x
y1=pt1.y
ldist=math.sqrt((x1-x0)**2+(y1-y0)**2)
return ldist
def
ptsLen(pts): # callabe in main()
only,只能在主程式使用
ldist=math.sqrt((pts[1].x-pts[0].x)**2+(pts[1].y-pts[0].y)**2)
return ldist
#------------------------------------------------------------------------------------------
def
IspointInCircle(pttest,ptCirBox0,ptCirBox1,radi):
#herafter are exclude within class
Ptxy,do'nt indent,不縮排
x=(ptCirBox0.x+ptCirBox1.x)/2
y=(ptCirBox0.y+ptCirBox1.y)/2
#不能直接使用
ptcen.x=(ptCirBox0.x+ptCirBox1.x)/2 &
ptcen.y=(ptCirBox0.y+ptCirBox1.y)/2
ptcen=Ptxy(x,y)
linet=line(pttest,ptcen)
#ltpt=math.sqrt((pttest.x-ptcen.x)**2+(pttest.y-ptcen.y)**2)
ltpt=linelen(linet)
ltpt=ptptDist(pttest,ptcen)
if ltpt< radi:
return
True
else:
return
False
def
RotatePoint(ptBerot,ptPivot,angrot ):
# rotation a point
#print('ptBerot.x,ptBerot.y,ptPivot.x,ptPivot.y',ptBerot.x,ptBerot.y,ptPivot.x,ptPivot.y)
#radt=math.sqrt((ptBerot.x-ptPivot.x)**2+(ptBerot.y-ptPivot.y)**2)#ptptlen(ptBerot,ptPivot)
#radt=ptclass.Ptptlen(ptBerot,ptPivot)
#pts=[]
#pts.append(ptBerot)
#pts.append(ptPivot)
#radt=ptslen(pts)
radt=ptptDist(ptBerot,ptPivot)
angorg=math.atan2((ptBerot.y-ptPivot.y),(ptBerot.x-ptPivot.x))
angrot=math.radians(angrot)+angorg
xrot=ptPivot.x+radt*math.cos(angrot)
yrot=ptPivot.y+radt*math.sin(angrot)
ptrotAft=Ptxy(xrot,yrot)
return ptrotAft
def
Ptverticaltoline(referPt,basePt0,basePt1) :#已知線外一點求垂線座標垂足點
#print('in= ',referPtX,
referPtY,basePt0x,basePt0y,basePt1x,basePt1y)
Ax =
basePt0.x
Ay =
basePt0.y
Bx =
basePt1.x
By =
basePt1.y
px =
referPt.x
py =
referPt.y
#print('Ax,Ay,Bx,By,px,py',Ax,Ay,Bx,By,px,py)
vAB_x =
Bx - Ax
vAB_y =
By - Ay
Ldist =
math.sqrt(vAB_x ** 2 + vAB_y **
2)
#print('Ldist',Ldist)
if Ldist >=
0.000001:
uAB_x = vAB_x / Ldist #'單位向量
uab的x分量
uAB_y = vAB_y / Ldist #'單位向量
uab的y分量
#print('uAB_x,uAB_y',uAB_x,uAB_y)
vPA_x = px - Ax
#print('vPA_x',vPA_x)
vPA_y = py - Ay
#print('vPA_y',vPA_y)
t =
uAB_x * vPA_x + uAB_y * vPA_y
ptvertX = Ax + t * uAB_x
ptvertY = Ay + t * uAB_y
ptvert=Ptxy(ptvertX,ptvertY)
return ptvert
def
ReflctPoint(referPt,basePt0,basePt1) :#點反射或鏡射
#print('in= ',referPtX,
referPtY,basePt0x,basePt0y,basePt1x,basePt1y)
Ax =
basePt0.x
Ay =
basePt0.y
Bx =
basePt1.x
By =
basePt1.y
px =
referPt.x
py =
referPt.y
#print('Ax,Ay,Bx,By,px,py',Ax,Ay,Bx,By,px,py)
vAB_x =
Bx - Ax
vAB_y =
By - Ay
Ldist =
math.sqrt(vAB_x ** 2 + vAB_y **
2)
#print('Ldist',Ldist)
if Ldist >=
0.000001:
uAB_x = vAB_x / Ldist #'單位向量
uab的x分量
uAB_y = vAB_y / Ldist #'單位向量
uab的y分量
#print('uAB_x,uAB_y',uAB_x,uAB_y)
vPA_x = px - Ax
#print('vPA_x',vPA_x)
vPA_y = py - Ay
#print('vPA_y',vPA_y)
t =
uAB_x * vPA_x + uAB_y * vPA_y
ptvertX = Ax + t * uAB_x
ptvertY = Ay + t * uAB_y
ptvert=Ptxy(ptvertX,ptvertY)
l1=math.sqrt((Ax-ptvertX)**2+(Ay-ptvertY)**2)
l2=math.sqrt((Bx-ptvertX)**2+(By-ptvertY)**2)
lt=math.sqrt((Ax-Bx)**2+(Ay-By)**2)
if
abs(lt-l1-l2)<=0.001:
lvert=math.sqrt((referPt.x-ptvertX)**2+(referPt.y-ptvertY)**2)
Xreflect=2*ptvertX-px
Yreflect=2*ptvertY-py
ptreflect=Ptxy(Xreflect,Yreflect)
return ptreflect
def
circleDraw(ptcen,ptonArc,npt=36,angbeg=0,angend=360):
canvas.create_line(ptonArc.x,ptonArc.y,ptcen.x,ptcen.y)
rad=ptptDist(ptonArc,ptcen)
xpts=[]
ypts=[]
angdel=(angend-angbeg)/npt
angdel=math.radians(angdel)
for i
in
range(npt):
xtpt=ptcen.x+rad*math.cos(angdel*i)
ytpt=ptcen.y+rad*math.sin(angdel*i)
xpts.append(xtpt)
ypts.append(ytpt)
if
abs(360.0-angend-angbeg)<=0.01
:
xpts.append(xpts[0])
ypts.append(ypts[0])
lines=[]
print(len(xpts))
for i
in
range(len(xpts)-1):
lines += [(xpts[i],ypts[i],xpts[i+1],ypts[i+1])]
canvas.create_line(lines,fill='red')
return xpts,ypts
def
from_rgb(rgbin):
return ("#%02x%02x%02x"
% rgbin)
def
CursorMove(event):
x,y=
event.x, event.y
global glxystr
glxystr=('x= ',x ,'
y= ',y)
lblxy.config(text=glxystr)
canvas.bind('<B1-Motion>',CursorMove)
def
CursorDown(event):
x,y=event.x,event.y
dc =
windll.user32.GetDC(0)
# get handler
rgb =
windll.gdi32.GetPixel(dc,event.x_root,event.y_root)
print('x,y,event.x_root,event.y_root',x,y,event.x_root,event.y_root)
r = rgb
& 0xff
g = (rgb
>> 8) & 0xff
b = (rgb
>> 16) & 0xff
print (r,g,b)
pti=Ptxy(event.x_root,event.y_root)
colr=get_pixel_colour(pti)
print('colr
in mousedown',colr)
return r,g,b
canvas.bind('<Button-1>',
CursorDown)
#canvas.bind('<B1-Motion>',CursorMove)
def
main():
ptb0=Ptxy(4,6)
ptb1=Ptxy(7,9)
pttest=Ptxy(3,3)
print('ptb0.x,ptb0.y',ptb0.x,ptb0.y)
print('ptb1.x,ptb1.y',ptb1.x,ptb1.y)
bolans=IspointInCircle(pttest,ptb0,ptb1,5)
print('bolans',bolans)
pt0=Ptxy(4,6)#ptb0
# copy ptb0 to pt0
pt1=Ptxy(7,9)#ptb1
linet=line(pt0,pt1)
ldist=linelen(linet) #呼叫引用class
line中之linelen()
"""
#??????????????????????????????????/'
ldist=ptptlen(pt0,pt1) #NameError: name 'ptptlen' is not
defined
#?????????????????????????????????????????
"""
print('ldist=',ldist)
pt0Base=Ptxy(50,50)
ptmove=ptMoveto(pt0Base,50,50)
canvas.create_oval(ptmove.x-9,ptmove.y-9,ptmove.x+9,ptmove.y+9,fill='gold')
ptorg,ptcopy=ptCopyto(pt0Base,150,148)
canvas.create_oval(ptcopy.x-10,ptcopy.y-10,ptcopy.x+10,ptcopy.y+10,fill='red')
pt1Base=Ptxy(450,450)
ptPivot=Ptxy(300,400)
angrot=45
ptBerot=Ptxy(100,150)
ptOrg=ptBerot
canvas.create_line(pt0Base.x,pt0Base.y,pt1Base.x,pt1Base.y,fill='blue',width=3)
col=get_pixel_color(49,46)
print('col
49,46',col)
colw=get_pixel_colorw(49,46)
print('col
49,46w',colw)
print('get_pixel_color(0,0)',get_pixel_color(0,0))
canvas.create_oval(pt0Base.x-5,pt0Base.y-5,pt0Base.x+5,pt0Base.y+5,fill='blue')
canvas.create_rectangle(ptPivot.x-5,ptPivot.y-5,ptPivot.x+5,ptPivot.y+5,fill='red',activefill='green')
canvas.create_text(ptPivot.x+5,ptPivot.y+5,text='pivot')
canvas.create_oval(ptOrg.x-5,ptOrg.y-5,ptOrg.x+5,ptOrg.y+5,fill='gold')
canvas.create_oval(ptBerot.x-5,ptBerot.y-5,ptBerot.x+5,ptBerot.y+5,fill='cyan')
canvas.create_text(ptBerot.x+5,ptBerot.y+5,text='ptbeRot&
ptbeRefct')
ptrot=RotatePoint(ptBerot,ptPivot,angrot)
canvas.create_rectangle(ptrot.x-5,ptrot.y-5,ptrot.x+5,ptrot.y+5,fill='green',activefill='red')
canvas.create_text(ptrot.x+5,ptrot.y+5,text='ptaftRot')
ptreflct= ReflctPoint(ptOrg,pt0Base,pt1Base)
canvas.create_rectangle(ptreflct.x-5,ptreflct.y-5,ptreflct.x+5,ptreflct.y+5)
canvas.create_text(ptreflct.x+5,ptreflct.y+5,text='ptaftRefl')
canvas.create_line(ptOrg.x,ptOrg.y,ptreflct.x,ptreflct.y,fill='gold',width=3)
ptcen=ptPivot
xpts=[]
ypts=[]
xpts,ypts=circleDraw(ptcen,ptBerot)
pti=Ptxy(400,300)
rgbin=(250,0,0)
id=set_pixel_color(pti,rgbin)
print('id=',id)
pts=[]
pts.append(pt0Base)
pts.append(pt1Base)
ldist=
ptsLen(pts)
print('lpts=
',ldist)
if
__name__ == '__main__':
main()
canvas.mainloop() |
